technical parameter:
| project | s-80l | s-90l | |
| spindle | |||
| spindle taper | hsk e40 | hsk e50 | hsk a63 |
| spindle speed | 30000rpm | 24000rpm | 20000rpm |
| spindle power | 7.5kw | 15kw | 18.5kw |
| spindle torque | 5.97nm | 17.9nm | 32nm |
| workbench | |||
| working desk size | 1000×500mm | 1000×500mm | 1000×600mm |
| t-slot (width * quantity) | 18×5 | 18×5 | 18×5 |
| spindle end to table | 120-620mm | 120-620mm | 120-720mm |
| workbench z maximum load | 400kg | 400kg | 800kg |
| journey | |||
| movement amount in the x-axis direction | 800mm | 800mm | 900mm |
| movement amount in y-axis direction | 500mm | 500mm | 650mm |
| movement amount in z-axis direction | 500mm | 500mm | 600mm |
| feed rate | |||
| rapid movement (xyz axis) | 30m/min | 30m/min | 30m/min |
| cutting feed rate | 1-12000mm/min | 1-12000mm/min | 1-12000mm/min |
| atc | |||
| tool magazine capacity | 20t | 24t | 24t |
| tool z largest diameter | φ75mm | φ75mm | φ75mm |
| tool z largest diameter | φ110mm | φ110mm | φ110mm |
| tool z maximum length | 130mm | 250mm | 250mm |
| tool maximum weight | 8kg | 8kg | 8kg |
| other | |||
| battery capacity | 20kva | 30kva | 35kva |
| machine size（xyz) | 2450*2850*2800mm | 2450*2850*2800mm | 2800*2900*2880mm |
| machine weight | 5400kg | 5500kg | 6800kg |
